23NM50N / 23n50 (ST) Mosfet Transistor (SH) TO-220F Code: 80377459

The 23NM50N is an N-channel power MOSFET featuring a 500V drain-source voltage, 17A continuous drain current, and 0.162 Ω on-resistance.

Key Specifications

• Polarity Type:N-Channel
• Drain-Source Voltage :500 V
• Continuous Drain Current :17 A
• Drain-Source On-Resistance :162 Ω (typical) / 0.19 Ω (max)
• Maximum Power Dissipation :125 W
• Gate-Source Voltage :±25 V

Technology and Application

• Technology Build:MDmesh™ II second-generation high-voltage technology
• Common Packages:TO-220, TO-220FP, TO-247, and D²PAK
• Target Uses:High-efficiency switch-mode power supplies (SMPS), DC-DC converters, and power factor correction circuits.
